Heinzmann PANDAROS DC 6-06 User Manual

7 Technical data
46 Positioner DC 6-06
7.3.5 PWM setpoint, stop signal analogue, actuator with disc rotor motor
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
T
18
C
B
D
A
E
M
DC ... 6-06
StG 6 .. 40 - 01
Actuator
Fuse
12 A
Control
on
Control unit
Common alarm
22 23 24 25
CU-01
1LH 19 20 21
StG actual position
with analogue signal
or PWM signal
0 V
analog/PWM
Stop analogue
Error reset
Supply voltage
12 V DC or 24 V DC
+
-
PWM setpoint
0 V
PWM
Fig. 6 Terminal connection diagram 3
– PWM setpoint, stop signal analogue, actuator with disc rotor motor
