10 Error handling
Positioner DC 6-06 63
Configuration error
10 Port is used as analogue input but not configured accordingly
15 Port is used as analogue output but not configured accordingly
20 Port is used as PWM input but not configured accordingly
25 Port is used as PWM output but not configured accordingly
30 Port is used as digital input but not configured accordingly
35 Port is used as digital output but not configured accordingly
40
The characteristic curve ActPosSetoint[FuelSetpoint] is not parameterized with a
rising characteristic
10.7 Emergency shutdown errors
The following list gives a summary of all the errors that either prevent starting or result in
an emergency shutdown during operation. The presence of at least one of these so-called
fatal errors will activate 3800 EmergencyAlarm.
These errors are described in detail in
Chapter
10.8 Error parameter list.
Error Cause
3050 ErrFeedback Error in the actuator feedback
3056 ErrFeedbackRef Error in the actuator feedback reference
3059 ErrFeedbackAdjust Error in the actuator auto adjustment
3060 ErrAmplifier Error in the amplifier
3075 ErrClearFlash Error when clearing the flash memory
(display in the bootloader)
3076 ErrParamStore Error when storing the E
2
PROM memory parameters
3077 ErrProgramTest Error in the ongoing test of the program memory
3078 ErrRAMTest Error in the ongoing test of the RAM memory
3089 ErrWatchdog Undefined program flow, internal program error
(display in the bootloader)
3090 ErrData No parameters, or checksum of parameters is incorrect
(always active after a program download)
3093 ErrStack Stack overflow, internal program error
3094 ErrIntern Exception, internal program error
An actuator auto adjustment (
8.1.2 Automatic calibration) cannot be
performed when a fatal error is present.
Note
