11 Parameter description
Positioner DC 6-06 71
11 Parameter Description
11.1 General
All the parameter groups are listed in
Table 15: Parameter groups. This provides an
overview of the number ranges on which certain functions can be found. The four
subsequent parameter tables (
Table 16: Parameter
Table 17: Measured Values and
Display Values
Table 18: Functions and
Table 19: Curves and Control Map) list each
individual parameter with a brief description and a reference to related chapters.
These four parameter lists explains all of the parameters which are defined in the
positioner. The defined level is given for each parameter. An operating tool such as
DcDesk 2000 or a hand programmer can only be used to view parameters whose level is no
higher than the level of the tool.
Parameters that require a save and control unit reset after a change are identified by
(RESET).
Only the first field parameter is given for curves and control maps; the parameter number
is identified by “ff” (and following).
No. Parameter Measured values Functions Curves
300 Control path/setpoint 2300 Control path/setpoint 4300 Setpoint
800 Switch functions 2800 Switch functions 4800
Configuration of the
input/output channels
3000 Current errors 5000 Error handling
3100 Error memory
7300 Actuator curve
1500
PWM inputs
Analogue inputs
3500
PWM inputs
Analogue inputs
5500
Configuration of analogue
input/output channels
1600
PWM outputs
Analogue outputs
3600 Internal measured values 5600 Analogue outputs
1700 Positioner 3700 5700 Positioner
1800 Status 3800 Status
1900 Servo loop 3900 Servo loop 5900 Servo loop
1950 Feedback 3950 Feedback 5950 Feedback
Table 15: Parameter groups
