11 Parameter description
Positioner DC 6-06 87
Name Meaning
5701 ActuatorTestMode
Level: 2
Range: 0..3
Page(s): 54
Selects the te
st mode for the actuator
0 = input from 1700
1 = rectangular from 1700  1701
2 = delta from 1700  1701
3 = sinusoidal from 1700  1701
5910 ActuatorOn
Level: 6
Range: 0/1
Page(s): 48, 54
Switches the
servo loop on/off
5911 Amplifier2QOr4Q
Level: 6
Range: 0/1
Page(s): 48
Operation of
the amplifier
0 = 4-quadrant (energizing in both directions)
1 = 2-quadrant (energizing in direction 100 %)
(RESET)
5920 ServoCurrentPCOn
Level: 6
Range: 0/1
Page(s):
Activates the actuator test mode to output the current
from 1920 ServoCurrentPC as a test setpoint to the
actuator
This function cannot be stored
5950 FeedbDigitalOrAnalog
Level: 6
Range: 0/1
Page(s): 48
Type of actuator feedback
0 = DC voltage signal
1 = coil feedback
(RESET)
5951 FeedbSlopeFallOrRise
Level: 6
Range: 0/1
Page(s): 48
Type of feedback signal curve
0 = rising out
put signal with rising filling
1 = falling output signal with rising filling
(RESET)
Table 18: Functions
