10 Error handling
Positioner DC 6-06 65
3050 ErrFeedback 3150 SErrFeedback
Cause: Error in the feedback system of the actuator, actuator not connected.
Reaction: - Control unit cannot be operated.
- Emergency shutdown.
Action: - Check the feedback cable to the actuator.
- Check the actuator and replace if necessary.
- Check the error limits for the feedback:
1952 FeedbackErrLow / 1953 FeedbackErrHigh
Reference: -
 8 Actuator and feedback
3053 ErrActuatorDiff 3153 SerrActuatorDiff
Cause: The difference between the target control path and the actual control path
exceeds 10 % of the total control path for more than one second. This
situation exists when the injector pump, the throttle, the linkage or the
actuator sticks or is not connected.
Reaction: - Error message.
- The error clears when the difference is below 10 % again.
Action: - Check the injector pump or throttle, replace if necessary.
- Check the mechanism (linkage).
- Check cable to the actuator.
- Check actuator, replace if necessary.
Reference:
 8 Actuator and feedback
3056 ErrFeedbackRef 3156 SerrFeedbackRef
Cause: Error in the feedback system of the actuator, actuator not connected.
Reaction: - Control unit cannot be operated.
- Emergency shutdown.
Action: - Check the feedback cable to the actuator.
- Check the actuator and replace if necessary.
- Check the error limits for the reference of the feedback:
1956 FeedbackRefErrL
ow / 1957 FeedbackRefErrHigh
Reference:
 8 Actuator and feedback
