Heinzmann PANDAROS DC 6-06 User Manual

11 Parameter description
Positioner DC 6-06 73
No. Name Meaning
1501 FuelSetPWMIn1RefHigh
Level: 4
Range: 0..100 %
Page(s): 35, 36
Upper referen
ce value of PWM input 1 for setpoint
selection
1504 FuelSetPWMIn3RefLow
Level: 4
Range: 0..100 %
Page(s): 35
Lower reference value of PWM input
3 for setpoint
selection
1505 FuelSetPWMIn3RefHigh
Level: 4
Range: 0..100 %
Page(s): 35
Upper referen
ce value of PWM input 3 for setpoint
selection
1506 FuelSetPWMIn1_Filter
Level: 4
Range: 1..255
Page(s): 35
Filter for PWM input
1 for setpoint selection
1508 FuelSetPWMIn3_Filter
Level: 4
Range: 1..255
Page(s): 35
Filter for PWM input
3 for setpoint selection
1510 AnaStop_Ref_0%
Level: 4
Range: 0.. 5V
or 0..22 mA
Page(s): 32
0 %
reference value of the analogue input for the stop
request
1511 AnaStop_Ref_100%
Level: 4
Range: 0.. 5V
or 0..22 mA
Page(s): 32
100 %
reference value of the analogue input for the stop
request
1512 AnaStop_ErrorLow
Level: 4
Range: 0.. 5V
or 0..22 mA
Page(s): 26, 34
Error lim
it for minimum value of the analogue input for
the stop request
1513 AnaStop_ErrorHigh
Level: 4
Range: 0.. 5V
or 0..22 mA
Page(s): 26, 34
Error lim
it for maximum value of the analogue input for
the stop request
1514 AnaStop_Filter
Level: 4
Range: 1..255
Page(s): 33
Filter value of the analogue input for
the stop request
