Table 2-3: Tilt Setup Menu (only always present in eDriveTC)
Menu Item Display Sequence Defaults Description
Tilt Comp Tilt Comp
> Off
[On, Off]
Default = Off
Allows the user to
enable or disable
the tilt sensor
functionality.
Antenna Height
(if Tilt Comp ON)
Antenna Height
> 10.0 ft (3 m)
'+/-XX.X Feet
Default = 10.0 ft
(3 m)
The user must input
the distance from
the ground to the
GPS antenna in feet
or meters
(depending on the
unit of measure
mode) for proper tilt
compensation.
Calibrate
(if Tilt Comp ON)
Press Enter to
Calibrate
0.24
Enter when Level
2.5
Retry when < 2°
Allows the user to
see the current
angle measurement
of the tilt sensor for
mounting
adjustment and to
enter a zero angle
calibration point
(refer to tilt
compensation
setup sequence on
page 19).
Diagnostics
(if Tilt Comp ON)
Ver 2.87
Angle +2.06
Displays the current
software version
and the calibrated
angle measurement
produced by the tilt
sensor. (See page
20.)
