MBX-4 User Guide
17
Receiver Layout and Connections
The MBX-4 receiver is easily installed, requiring only power, data,
antenna, and ground connections. Figure 1-1 illustrates the required
receiver cable connections.
Warning!
The MBX-4 receiver provides 10 VDC across the antenna port labeled
“ANT.” Connection to incompatible devices may result in damage to
equipment. No voltage is provided on the GPS port and any voltage
applied to this port from an external GPS product is DC-blocked for
protection of the MBX-4.
