MBX-4 User Guide
29
Magnetic Mount
The magnetic mount, can be used to install the MGL-4 antennas on any
ferrous surface such as the roof of a vehicle. It consists of a mounting
extension three inches long, attached to a circular metal disk, housing a
magnet. A Mylar cover on the bottom of the mount protects the
mounting surface from abrasion. (Hemisphere GPS part number.
A three inch diameter zinc plated steel disc and a double sided adhesive
foam pad are included with the magnetic mount to attach the magnetic
mount to non-ferrous surfaces, such as fiberglass rooftops. For such an
installation, remove the protective backing from both sides of the
adhesive foam pad, and affix the foam pad to the non-ferrous surface.
Place the disc on top of the foam pad. You can then place the magnetic
mount securely on the metal plate, and remove as necessary.
The stem of the magnetic mount is removable from the base and
facilitates a 5/8” thread commonly used in the GIS and mapping
industry.
