3: MBX-4 Configuration and Operation
Back
Returns the MBX-4 to the top menu level.
Position Status (BX-E Mode Only)
The Position Status section of the menu tree provides access to BX-E
GPS position and navigation status information provided by an external
GPS sensor outputting the associated NMEA 0183 GPS message
strings.
Lat
Displays the current latitude in degrees, minutes, decimal minutes
(DM.M) as input from an external GPS receiver. This information is
parsed from the NMEA $GPGGA message string.
Lon
Displays the current longitude in degrees, minutes, decimal minutes
(DM.M) as input from an external GPS receiver. This information is
parsed from the NMEA $GPGGA message string.
1 L a t 5 1 4 6 . 2 3 4 N
¨ Focus Line
2 L o n 1 1 4 0 3 . 1 4 3 W
3 H g t 1 0 3 9 . 0 M
4 H d g 1 9 . 7 o t r u e
5 V e l 2 4 . 4 K
6 U T C 1 1 : 4 7 : 3 6
7 A g e 7 . 0 s
8 S V C o u n t 0 9
9 H D O P 1 . 9
1 B a c k
