MBX-4 User Guide
43
SNR
Ratio of SS over computed noise floor in dB, refer to Chapter 3 for
information
MTP
Message throughput (correct data ³ total data x 100%)
Q
Number of consecutive 30 bit RTCM words received correctly (max Q
count = 25).
Unselected
BX
Name of the beacon to which the receiver is tuned. This field is only
updated if a specific beacon is selected from the receiver's Global
Beacon Table.
ID
Reference station identifier as contained within the RTCM broadcast
messages.
H
Health of the transmitting beacon. Table 3-3 defines the various health
values.
Table 3-3: Beacon Health Status Values
Health Code Indication
0 – 5 Reference Station Transmission Broadcast -
Monitored
6 Reference Station Transmission Broadcast –
Un-monitored
7 Reference Station Not Working
