V103/113 Vector User Guide Chapter 2-Installation Page 24 of 35
Default Parameters
Table 2-4 and Table 2-5 provide details on the default port settings, available baud rates, differential age,
elevation mask, and default differential mode.
Note: Use the $JSAVE command to save changes you make to the V103/113’s configuration for the changes
to be present in subsequent power cycles.
Table 2-4: Default Port Settings
Port Baud Rate NMEA Messages Update Rate
Port A (RS-
232)
19200 GPGGA, GPVTG, GPGSV, GPZDA,
GPHDT, GPROT
1 Hz
Port C (RS-
232)
19200 GPGGA, GPVTG, GPGSV, GPZDA,
GPHDT, GPROT
1 Hz
Power
RED (+)
BLK (-)
6 - 36 VDC
Note: The default update rate for NMEA 0183 messages is 1 Hz. 10 Hz is the standard
maximum rate, but you can purchase a subscription to upgrade the output rate to 20 Hz.
Table 2-5: Default Parameters
Unit Parameter Specification
V103 and V113 Max DGNSS age (correction age) 2700 seconds
Elevation mask 5°
Differential mode V103: SBAS
V113: Beacon
V113 (internal
beacon parameters)
Frequency selection Automatic
MSK rate selection Automatic
