AXEL
The Axel is a fully assembled cantilever sliding gate for passageways up to 7 me-
ters.
Applications are construction sites, industrial buildings, storage areas and garden &
landscape.
Illustration 4: Axel sliding gate terms
Top guiding
End stop
Slam support
End stop
Bottom rail
Running wheels
Foundation
Run-in
Slam post
Guide column
Mesh panel
Swivel
