Heras Delta - Locking Closing Protection with Locking Pin; Unlocking Cloing Protection with Locking Pin

EN – Translation of the original user manual - 1.1 | 2022
22
Illustration 14: Closing protection for Delta/uGate sliding gate
5.2.1.1 Locking closing protection with locking pin
 Put the locking pin in the “LOCKED” position.
 Slide the gate fully open at an appropriate speed. The spring-loaded locking
pin will automatically engage the hole in the locking plate. The gate is now
locked.
 Check that the leaf is locked.
5.2.1.2 Unlocking cloing protection with locking pin
 Fully retract the locking pin and turn it a quarter turn.
 Release the locking pin. The gate is now unlocked.
 Hold the leaf firmly so that any gusts of wind do not cause unintended
movements.
 Close the gate.
UNLOCKED
LOCKED
Locking pin
Blocking
plate
