5.2.2 CLOSING PROTECTION AXEL
With the Axel, the closing protection consists of a comb that hooks into a gear rack.
The comb is attached to the underside of the guide column between column and
gate leaf. The gear rack part of the gate leaf. By putting the swivel lever in the
closed position, see 5.1.5, the cam hooks into the rack, which secures the gate leaf
against unintentional movement.
Illustration 15: Comb and gear rack Axel
5.2.2.1 Locking closing protection with comb
 See chapter 5.1.5.
5.2.2.2 Unlocking closing protection with comb
 See chapter 5.1.6.
Comb
Gear rack
