26/32 – User Manual
MIDI messages received by DJ Console Rmx:
MIDI control
MIDI message
Value description
LED Scratch
Bx 29 Value
00: Off – 7F: On
LED Left Play
Bx 0B Value
00: Off – 7F: On
LED Left Cue
Bx 0C Value
00: Off – 7F: On
LED Left Headphone Cue
Bx 14 Value
00: Off – 7F: On
LED Left Source
Bx 13 Value
00: Off – 7F: On
LED Left Sync
Bx 07 Value
00: Off – 7F: On
LED Left Beatlock
Bx 08 Value
00: Off – 7F: On
LED Left Reset
Bx 11 Value
00: Off – 7F: On
LED Right Play
Bx 23 Value
00: Off – 7F: On
LED Right Cue
Bx 24 Value
00: Off – 7F: On
LED Right Headphone
Cue
Bx 18 Value
00: Off – 7F: On
LED Right Source
Bx 17 Value
00: Off – 7F: On
LED Right Sync
Bx 1F Value
00: Off – 7F: On
LED Right Reset
Bx 20 Value
00: Off – 7F: On
LED Right Beatlock
Bx 15 Value
00: Off – 7F: On
Blink LED Scratch
Bx 59 Value
00: Off – 7F: On
Blink LED Left Play
Bx 3B Value
00: Off – 7F: On
Blink LED Left Cue
Bx 3C Value
00: Off – 7F: On
Blink LED Left
Headphone Cue
Bx 44 Value
00: Off – 7F: On
Blink LED Left Source
Bx 43 Value
00: Off – 7F: On
Blink LED Left Sync
Bx 37 Value
00: Off – 7F: On
Blink LED Left Beatlock
Bx 38 Value
00: Off – 7F: On
Blink LED Left Reset
Bx 41 Value
00: Off – 7F: On
Blink LED Right Play
Bx 53 Value
00: Off – 7F: On
Blink LED Right Cue
Bx 54 Value
00: Off – 7F: On
Blink LED Right
Headphone Cue
Bx 58 Value
00: Off – 7F: On
Blink LED Right Source
Bx 57 Value
00: Off – 7F: On
Blink LED Right Sync
Bx 5F Value
00: Off – 7F: On
Blink LED Right Beatlock
Bx 60 Value
00: Off – 7F: On
Blink LED Right Reset
Bx 55 Value
00: Off – 7F: On
Hercules has released a MIDI Mapper application for the DJ Console Rmx: this software allows
you to change the DJ Console Rmx’s MIDI messages and values.
The MIDI Mapper application is intended for advanced users familiar with the MIDI standard and
can be downloaded from http://ts.hercules.com.
