Appendix B - Vanguard Optima Specifications
Model Number Vanguard Optima
Maximum Engraving Area 18 x 12 inches (457.2 x 304.8 mm)
Maximum Engraving Speed 25 inches per second (635 mm/s)
Laser Source LX25 C02 Laser Tube
Laser Beam Spot Size Diameter
• 1.5 inch Focal Length (optional) 0.003 inches (.08 mm)
• 2.0 inch Focal Length (standard) 0.005 inches (.13mm)
• 2.5 inch Focal Length (optional) 0.007 inches (.18 mm)
• 4.0 inch Focal Length (optional) 0.013 inches (.33 mm)
Repeatability +/- 0.002 inches (+/- .06 mm)
Interfaces Parallel = Centronics
Serial = RS-232C (PC)
Serial = Phone Jack (MAC)
Memory Size 4MB (upgradeable to 64MB)
System Dimensions 29” wide x 30” deep x 17” tall
System Weight 25 Watt - 150 lb.(68 kg)
Safety Classification Class I
Focal Plane (Z axis) Adjustment 5 inches (127 mm)
Facility Requirements
Electrical Power:
25 Watt - Single phase, 120 VAC, 50/60 Hz, 10 Amp (US Version)
25 Watt - Single Phase, 220 VAC, 50/60 Hz, 5 Amp (International Version)
Exhaust:
200 CFM minimum at 6 inches of static pressure
Cooling:
25 Watt - Air cooled ambient temperature less than 80 degrees F (25 degrees C)
Specifications are subject to change without notice.
