Hermes VANGUARD OPTIMA - Acrylic Engraving and Cutting

Sample Materials 8-3
ACRYLIC - CAST AND EXTRUDED
TYPE
POWER
SPEED
PPI
PASS
DEPTH
LIGHT RASTER ENGRAVING
25
100
500
1
.001”
COMMENTS:
Remove original factory masking from the engraving surface. Leave the masking on the non-
engraved surface to prevent accidental scratches.
TYPE
POWER
SPEED
PPI
PASS
DEPTH
DEEP RASTER ENGRAVING
100
70
500
1
.010”
COMMENTS:
This sample engraved deeper than the first sample. Engrave through original masking.
Engraving too deep will lose detail.
TYPE
POWER
SPEED
PPI
PASS
DEPTH
VECTOR ENGRAVING
5
4.0
500
1
.2”
COMMENTS:
Engrave with or without masking.
TYPE
POWER
SPEED
PPI
PASS
DEPTH
VECTOR CUTTING
75
.8
500
1
.2”
COMMENTS:
For the best results, remove the original masking on both sides. Re-mask with transfer tape.
Moisten both sides with water from a spray bottle. Elevate the material at least 1/8” off of the
engraving table.
