1-6 Safety
Locations (2): One is on the back of the laser system’s cooling fan cover. Visible from the
outside under normal operating conditions when viewed from the backside of the system. The
other is on the plastic shield over the back of the power entry module.
Locations (1): On the side of the laser system next to the ON/OFF switch and plug receptacle.
Visible from the outside under normal operating conditions.
Locations (1): Inside of the laser systems cooling fan cover next to the chassis ground green
wire. Not visible under normal operating conditions. Visible only when cover is removed for
servicing only.
Locations (1): On the outside motor cover of the optional Rotary Fixture. Visible under normal
operating conditions.
Serial Tag
Locations (1): On the back side of the laser system in the lower right corner if viewing the
machine from the back side. Visible under normal operating conditions.
