HERO DESTINI 125 PROGRAMMED FI - ESSENTIAL INDIVIDUAL COMPONENTS; Ignition switch

25
Ignition switch
ESSENTIAL INDIVIDUAL COMPONENTS
The ignition switch (1) is on the right side
below the steering.
(4) Seat open
(3) Steering lock position
(1) Ignition switch
(2) Ignition key
(5) Fuel open
Key Position
Function
Key removal
The engine can be started, turn signal lamps,
horn, tail/stop lamp, fuel gauge and passing
lamp can be operated. Programmed FI
malfunction indicator lamp (MIL) illuminates and
i3s indicator glows for 2 seconds.
Engine cannot be started and cannot be operated.
Steering can be locked.
“LOCK”
Key cannot be removed
Key can be removed
Key can be removed
Seat can be opened by rotating the key
anticlockwise.
“SEAT OPEN”
Key can be removed
“FUEL OPEN”
Fuel filler cap can be opened by pushing the key
inwards and rotating it into the clockwise direction.
Key can be removed
