36
(3) USB charger connector
(4) Center compartment
(2) Boot lamp connector
4
Installation
•
Remove the center compartment (4).
Installation is in the reverse order of removal.
NOTE
Park the vehicle on its main stand when
servicing the vehicle with the center
compartment removed.
(b) Center cover
Removal
Remove four screws from the center cover.
Remove the center cover (2).
(1) Center cover screws (2) Center cover
2
Installation
Installation is in the reverse order of removal.
(c) Body cover
•
Remove the center compartment (page 35).
•
Remove the tray sub assembly (2).fuel
•
Remove the center cover (page 36).
•
Remove the tray sub assembly bolt (1).fuel
Removal
(1) Bolt (2) Fuel tray sub assembly
•
Slightly lift up the center compartment
from the rear and disconnect the boot
lamp connector (2) and USB charger
connector (3).
2
3
2
1
1
To Next Page
