31
•
Bharat Petroleum Corporation Limited.
OIL CAPACITY: 1.25 liters
Do top up if oil level reaches towards the lower
level mark or every 3000 km whichever is
earlier.
•
Savita Oil Technologies Limited.
Engine oil level inspection/
Top up process
Check engine oil level each day before
operating the vehicle.
The oil level dipstick (1) is on the right
crankcase cover for measuring oil level. Oil
level must be maintained between the upper
(2) and lower (3) level marks on the oil level
dipstick.
(1) Oil level dipstick (2) Upper level mark
(3) Lower level mark
Oil circulation inspection
•
Quantity of oil to be filled is 1.1 liters
(approx.) during oil change when right
crankcase cover is not removed.
•
Remove the tappet inspection cover. Slowly
accelerate and check the engine oil entry
into the cylinder head, engine oil will splash
out from the tappet inspection cover
opening.
•
To drain the oil, remove the oil level dipstick
and drain bolt (1).
•
Reinstall the oil level dipstick and check for
oil leaks.
•
Remove the oil level dipstick and check the
oil level.
•
Start the engine and allow it to idle for few
minutes.
•
If required, add the specified oil up to the
upper level mark. Do not overfill.
•
Fill the crankcase through the oil filler hole
with (approximately) of the 1.1 liters
recommended grade oil.
•
Reinstall the oil level dipstick with a new
O-ring.
Drain engine oil with the engine warm and the
vehicle on its main stand.
•
Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
•
After checking the oil circulation, install the
tappet inspection cover.
•
After the oil has completely drained, reinstall
the drain bolt with a new sealing washer (2).
Engine oil replacement process/
•
Park the vehicle on its main stand.
•
Stop the engine and wait for 2-3 minutes.
•
Start the engine & let it idle for 3-5
minutes.
2
1
3
