HERO Passion Xpro - VEHICLE VIEWS

2
(7) Neutral indicator
(3) Clutch lever
(2) Turn signal switch
(4) Pass lamp switch
(5) Dimmer switch
(6) Rear view mirror
(1) Horn switch
(8) Left turn signal indicator
(9) High beam indicator
(10) i3s indicator
(11) Speedometer
(12) Side stand indicator
(23) Leg guard
(17) Front brake lever
(14) Mode/Reset button
(18) Throttle grip
(16) i3s switch
(21) Ignition switch with steering lock
(15) Master cylinder (Optional)
(20) LCD panel
(13) Right turn signal indicator
(22) Fuel tank cap
(19) Electric starter switch
*Accessories and features shown may not be part of standard fitment.
TOP VIEW
