(7) Main stand
(1) Air suction valve (inside)
(2) Fuel valve
(3) Carburetor
(5) Rider footrest
(4) Gearshift pedal
(6) Side stand switch
(10) Seat lock/Helmet hanger
(9) Saree guard with women
(11) Rear reflex reflector
pillion step
(8) Side stand
(12) Rear turn signal lamp
(13) Licence plate lamp
(14) Tail/Stop lamp
(19) Front reflex reflector
(16) Seat
(15) Rear grip
(17) Left side cover
(18) Front turn signal lamp
*Accessories and features shown may not be part of standard fitment.
LEFT SIDE VIEW
