(3) Brake fluid reservoir (For
#IBS) (inside)
(4) Kick starter pedal
(2) Rear master cylinder (For
#IBS) (inside)
(1) Pillion foot rest
(10) Front disc (Optional)
(9) Caliper (Optional)
(8) Oil level dipstick
(7) Rear brake pedal
(5) Rider footrest
(6) Starter motor
(12) Headlamp
(13) Front visor
(14) Battery compartment (inside)
(15) Rear suspension
(16) Hugger fender (optional)
(11) Front suspension
#IBS- Integrated Braking System
*Accessories and features shown may not be part of standard fitment.
RIGHT SIDE VIEW
4
322
4
5
6
7
8
9
10
11
12
13
15
16
1
14
