15
(2) Side stand switch
2
(1) Side stand indicator
A side stand switch (2) is provided in the side
stand, when the vehicle is parked on side stand
(Ignition Switch “ON”), the switch enables the
side stand indicator lamp to glow on the
speedometer panel.
(1) Fuel tank cap (2) Key hole cover
(3) Ignition key
1
2
3
Fuel tank
Fuel tank capacity is 13 litres (Minimum)
including reserve supply of 1.0 litre (Usable).
Ÿ To unlock and remove fuel tank cap (1), lift
the key hole cover (2), insert ignition key
(3) turn it clockwise and remove the cap.
Ÿ Do not overfill the tank, there should be no
fuel in the filler neck (4). Fill the tank with
fuel (5) as shown.
5
4
(4) Filler Neck (5) Fuel
Ÿ To lock, position the cap with “ ” mark ▲
facing towards the front, back on the opening
and press gently. The key springs back to the
normal position and the cap gets locked.
1
