Hesai Pandar128 User Manual

22
4.2 Settings
1. Reset All Settings
By clicking the “Reset All Settings” button on the top-right corner,
all configurable parameters in the Settings page and the Azimuth
FOV page will be reset to their default values.
The default values are shown in the left-hand screenshot and in
Section 4.3.1.
2. Control IP – VLAN
VLAN Tagging can be used when the receiving host also supports
VLAN function.
▪ Checkthe VLAN checkbox andinput a VLAN ID (range: 1~4094)
for the LiDAR unit.
▪
Set the VLAN ID of the receiving host to be the same.
3. Settings – Destination IP
Mode
Destination IP
Broadcast (default)
255.255.255.255
Multicast
239.0.0.0~239.255.255.255
Unicast
Same as the PC’s IP address
