HHO Plus DC2000 - Relay to Dry Cell Connection

DC2000 – Installation Manual 37
HHO Plus, Alternative Energies, Lta – Travessa das Serras 33, Vieira de Leiria, Portugal – Tel. 00351244697116 – Email: info@hhhoplusgas.com
Electric connection from the relay (Position 87) to the dry cell
Materials to make the connection
1
1
1
1
Female crimp
terminal
Red electric cable
Snap lock splice
connector
Relay
Sequence of parts to make the connection
+ + + +
