DC2000 – Installation Manual 9
HHO Plus, Alternative Energies, Lta – Travessa das Serras 33, Vieira de Leiria, Portugal – Tel. 00351244697116 – Email: info@hhhoplusgas.com
Positioning the Bubbler
The bubbler will serve two purposes: cleaning the HHO gas and act as a safety barrier. When HHO gas is
produced from the dry cell, some small water vapor is produced as well because the water will get a little bit
hot with the passage of current. This water vapor can
carry tiny particles of electrolyte which can cause
damaging corrosion. As the HHO bubbles rise up the
column of water inside the bubbler they are "scrubbed"
of any electrolyte particles that were attached to the
water vapor. The result is much cleaner HHO gas.
In the event of a flashback, the bubbler also acts as a
safety barrier. If a flame reaches the bubbler and ignites
the HHO that has accumulated at the top, the water
column will prevent the HHO from going on to the dry
cell because the flame cannot skip from bubble to
bubble.
Make sure that bubbler is installed above the water tank to accomplish the gravity head needed for a correct
“filtering” of the HHO gas. Please take a look at the pictures below:
EXAMPLE OF A COMPRESSED
INSTALLATION
