Hi Sharp HS-AHR600 - System Configuration

12
3 Main menu setup guide
Click right mouse or press ESC button on the front panel, the control bar will display on the screen, refer to
Fig 4-1:
1
Single
Full channel
2
Multi
4ch:1/4, 8ch:1/4/9, 16ch:1/4/9/16
3
E-Zoom
Live/playback digital zoomx2
4
Audio
Audio channel setup and volume
5
PTZ
Into PTZ control mode
6
Record
Manual record
7
Playback
Playback the nearest file
8
Main Menu
Into main OSD
9
Dwell
Channel sequence(only 16CH)
Fig 4-1 main menu toolbar
Click Menu button, the interface will pop-up as Fig 4-2; press MENU button on the front panel or
operate with remote controller also can display the main menu.
Main OSD
Fig 4-2 system setup
Full channel switch, camera 1 ~ 4 or camera 1 ~ 8, camera 1 ~ 16
①
②
③
④
⑤
⑥
⑦
⑧
