1.2 Front Panel Instructions
Notice: The pictures are only for reference; please make the object as the standard.
Label Name
Function
REC / FOCUS
Manual record / focus adjustment(PTZ)
PLAY / IRIS
Enter Playback/ iris adjustment (PTZ)
REW / SPEED
Fast rewind on playback mode /speed adjustment (PTZ)
FF / P.T.Z.
Fast forward on playback mode /enter PTZ mode
MENU / +
Enter menu page / increase value
BACKUP / -
Enter backup page / decrease value
STOP / ESC
Stop playback on playback mode /
Exit menu or jump back to previous page
Split / Direction
Key
Switch split / Move selected item
Enter
Validate action
USB
Connect USB thumb drive or mouse
IR receiver
Remote receiver
