Hi-Target A8 Series User Manual

A8 GNSS RTK System Operation Manual
Introduction
Most of the operations of A8 receiver can be done by the three
buttons on the mainframe pa nel.
Buttons on the panel:
Satellite Led Status Led
Power Led
Function Button F1
Function Button F2
Power Button
Figure4-1 Mainframe Panel
Explanations of buttons operations and leds hints as below:
Operations Explanation
Single click button Press a button less than 0.5 second
Double click button Double click the button while the
clicking interval should be between 0.2 to 1
second
Long pressing button Pressing button more than 3 second
17
