Ports and Main Accessory
Point: All above are for facing the main frame, it’s the
face ic on for the socket of bottom main frame
( The plug welding surface)
Differential Antenna
Refer to Figure 8-3, the differential antenna is an essential part
both to Base and Rover which transmits the differential signal for Base
while receiving the differential signal for Rovver.
Differential Antenna Installation
Refer to Figure 8-4，holding the bottom of differential
antenna and assemble it with clockwise rotation. On the contrary you
can disassemble the differential antenna.
