A8 GNSS RTK System Operation Manual
Warning: When install the differential antenna, make sure
rotating the right bottom fixed nut of differential
antenna, don’t grip the top parts of differential
antenna, Otherwise, it will make poor connect and
reduce the working distance.
Y Type Data Cable
Eight-pin Port
USB Port
Serial Port
Figure 8-5 Y Type Data Cable
67
