Ports and Main Accessory
Eight-pin Port: to connect with the eight-pin port of A8 receiver
USB Port: to connect with PC USB for data downloading
from A8
Serial Port: to connect with PC serial port for A8 firmware
upgrade, receiver settings, manage static data file, set radio
parameters, etc.
Warning: 1. When connecting plugs of all the A8 GNSS
RTK system,( See below) please make sure to make two
red points aligned , one on plug and the other in the A 8
receiver socket, otherwise, it will bring damage both to
socket and plug.
7. When finish your work, please take out of plug directly.
Don’t spin th e plug.
8. In order to protect the plug, please store the cable in a
good status and places without extruding.
Plug red dot
Socket red dot
