3. Parameter Sittings of Base Station
The base station parameters include setting the target height, base station coordinates,
working mode and corresponding parameters, message format, elevation angle, and so on.
After completing the relevant parameter editing, click the Settings button in the upper right
corner, and the software prompts Setup Successful!
Figure 2-4-3 Receiver Settings Figure 2-4-4 Choice of Radio
Figure 2-4-5 Other Settings
4. Rover Settings
The mobile station receiver is fixed on the telescopic centering pole, and the handbook is
fixed on the handbook carrier. The mobile station settings are basically the same as the
base station, mainly including the working mode setting, the altitude angle, and the like.
The difference is that the mobile station working mode increases the handbook difference.
Figure 2-4-6 Choice of Radio Figure 2-4-7 Other Settings
