V30 Plus GNSS System User Manual
15
3.1 Technical specification
Configuration
Detailed Indicators
GNSS
Configuration
Satellite Signals Tracked
Simultaneously
System: Multi-star System Core (UB4B0M)
Channels: 432
BDS: B1, B2, B3
GPS: L1, L2, L5
GLONASS: L1，L2
GALILEO: E1, E5a, E5b
QZSS: L1,L2,L5
SBAS: L1
Output Format
ASCII: NMEA-0183, Binary Data
Positioning Output
1Hz-20Hz
Static Data Format
GNS and RINEX
Message Type
CMR, RTCM2.X, RTCM3.0, RTCM3.2
Network mode
VRS; NTRIP
System
Configuration
Operating System
Linux
Data Storage
Built-in 8G Memory
Starting Time
3s
Accuracy and
Reliability [1]
RTK Single Baseline
Horizontal: 8 mm + 1 ppm RMS
Vertical: 15 mm + 1 ppm RMS
Network RTK
Horizontal: 8 mm + 0.5 ppm RMS
Vertical: 15 mm + 0.5 ppm RMS
Static and Fast Static
Horizontal: 2.5 mm + 0.5 ppm RMS
Vertical: 5 mm + 0.5 ppm RMS
DGPS
Plane accuracy: <=1.5 m RMS
Initialization Time
< 10s
Initialization Reliability
> 99.99%
Communication
I/O port
5-pin interface, Mini USB interface, TNC antenna interface,
SIM card slot
Internal 4G Cellular
Mobile
TDD-LTE/FDD-LTE/EDGR/WCDMA/GPRS/GSM
Wi-Fi
802.11b/g, WIFI hotspot service available
Bluetooth
Bluetooth® 4.0/2.1+EDR,2.4GHz
External UHF
External UHF:
Power: 5W/25W available
Frequency: 410MHz~470MHz
Protocol: TRIMTALK450S，TRIMMARK III，TRANSEOT
Transmission rate: 19.2kbps / 9.6kbps adjustable
Channel: 8 channels adjustable and configurable
Internal UHF
Built-in Transceiver Integrated Radio;
Power: 1W/2W/4W available
Frequency: 403MHz~473MHz
Protocol: HI-TARGET，TRIMTALK450S，SOUTH，CHC，
TRIMMARK III，TRANSEOT，SATEL-3AS
Number of channels: 116 channels (16 are configurable)
User Interface
Button
Single Button
Indicator Lamp
Satellite Lamp, Signal Lamp, Power Light
Function
application
Advanced Features
NFC IGRS, Web UI interaction, U disk firmware upgrade
Smart application
Intelligent voice, DIY voice, function self-test
Remote Service
Message push, online upgrade
Internal Battery
2×5000mAh Lithium-ion Rechargeable And Removable
battery RTK rover (Cellular) ≥10 hours[2]
External Power
6-28V DC External Power Input With Over-Discharge
Protection
