VertX V1000 (CS) Quick Installation Guide
I nt roduction
VertX™ CS is the first family of access controllers designed specifically for alarm dealers for direct
connection to central stations. Because it was designed with the central station in mind, VertX CS works
with software from leading central station automation providers, including Bold Technologies, DICE, Micro
Key, and Patriot Systems.
The V1000 is designed to control readers, door contact inputs and relays through the RS-485 loop and any
combination of up to 32 Interface Panels (V100 Door/Reader Interface, V200 Input Monitor Interface and/or
V300 Output Control Interface). In addition, the V1000 Access Controller manages communications with the
central station automated software.
Part s List
Description Quantity
VertX™ V1000 Access Controller 1
Note: The V1000 controller has a plastic base and is covered with a Plastic or Mylar cover.
- Lithium Battery 1
- Mounting screws 4
- 2.2K EOL resistors 8
- HID Serial Adapter cable (P/N 70007) 1
- Quick Installation Guide 1
- Installation Wiring Diagram Example 1
Note: One or more VertX Interface panels are required.
Note: A modem and RS-232 Serial cable must be purchased separately if your installation includes a modem.
Product Specificat ions
Description Specification
Power Supply 12-16VDC
Maximum current at 12VDC per V1000 1 Amp
Average operating current at 12VDC 210mA
Operating temperature range 32°-122°F (0°-50°C)
Humidity 5% to 95% non-condensing
Cable Specificat ions
Cable Type Length Specification
Use Belden 3105A, 22AWG twisted pair, shielded 100Ω cable, or
equivalent.
RS-485 * 4000 feet (1220 m) to host
Use any RS232 Serial modem cable specified by the modem
manufacturer.
15 feet (4.57 m) for RS232 Serial
modem cable
RS-232
HID Serial Adapter cable, P/N 70007.
6 inch (15.24 cm) adapter
2-conductor, shielded, using ALPHA 1292C (22AWG) or Alpha 2421C
(18AWG), or equivalent.
Input Circuits * 500 feet (150 m)
2-conductor, using ALPHA 1172C (22AWG) or Alpha 1897C (18AWG),
or equivalent.
Output Circuits * 500 feet (150 m)
