VertX Installation Worksheet
I nst a lla t ion W orksheet
This installation worksheet is provided for you to have a historical record of your system settings. Complete
each appropriate field, and keep this worksheet in a safe location. Record if the input is wired: 1) N/O or
N/C, 2) Unsupervised or Supervised (resistor values), and 3) what type of device is attached.
Record if output is wired: 1) N/O or N/C and 2) what type of device is attached.
V1000/V2000 Information:
Customer Name: Contact:
Installed Location: MAC Address:
Modem Model: RS232 Port #: Phone #:
Hostname: IP Address:
Tamper: AC Fail: BATT Fail:
Input 1: Input 2: Relay 1: Relay 2:
V100-Series Information (If V2000, there is a V100 at Interface Address 0 built-in):
Interface Type:
Interface Address: (0-31)
(V100, V200, V300, V2000)
Tamper: AC Fail: BATT Fail:
Reader 1: Reader 2:
V100 Door /
Interface
Reader
Door Switch 1: REX 1: Door Switch 2: REX 2
Strike Relay 1: Aux Relay 1: Strike Relay 2: Aux Relay 2:
Input 1:
Input 2: Input 3: Input 4:
Input 5: Input 6: Input 7: Input 8:
V200 Input
Interface
Monitor
Input 9: Input 10: Input 11: Input 12:
Input 13: Input 14: Input 15: Input 16:
Relay 1: Relay 2:
Relay 1: Relay 2: Relay 3: Relay 4:
V300 Output
Interface
Relay 5: Relay 6: Relay 7: Relay 8:
Control
Relay 9: Relay 10: Relay 11: Relay 12:
Input 1: Input 2:
