VertX V1000 (CS) Quick Installation Guide
St e p 4 Com m unicat e
Now that the V1000 is connected, contacted and configured, contact the Central Station to test the system.
Basic setup is now complete!
Additional trouble-shooting tools are available on the
System Status and Supplemental Configuration (page
14) screens.
Appendices
Trouble- shooting
Syst em Status
System Status provides a technician with a method of validating the VertX installation, field wiring and installed
devices. Perform the System Status at any time after the VertX controller has been installed and power is
available. In addition, a technician may perform a system status as many times as necessary.
System StatusUpon startup, the page will discover all connected and powered V100-Series devices attached
to the controller and displays the inputs, outputs, and host status.
Legend to determine the meaning of the different images. Reference the
Add Unconfigured By clicking you can configure the V1000 for the attached panels and readers. The
assumption is that two readers are attached to any V100 interface panel and that both readers are Wiegand
card only. Once the configuration is complete, the VertX software will refresh.
Restore Previous button becomes available. Once the page refreshes, a
The
Restore Previous button enables the technician to use the previously saved configuration.
Supplem e ntal Configura t ion
Supplemental Configuration provides the ability to view and configure system inputs and outputs
These buttons provide navigation to the following functionality:
Configure - configure inputs, outputs and door characteristics for a V1000, V100, V200, and V300
System Time - update System Time
Update System – updates the interface boards firmware
Configur e
Configure provides the ability to view and modify system inputs and outputs and door characteristics.
Save button will write modified values to the interface board. Upon successful validation, the
October 2006 Page 14 of 20
© 2006 HID Global Corporation. All rights reserved.
