7.4 ELECTRICAL CONNECTION
Open the electrical panel, introduce the supply cable and the other necessary cables on the dedicated holes, realize the connections
on the clamps and close the panel.
The ground lead is compulsory. The installer should provide the grounding wire with the dedicated
clamp located within the electrical panel, labelled with the indications.
Wiring must be carried out when the power supply is disconnected. DANGER OF DEATH!
The electrical connection, the power cables and the protections must be implemented according to the electrical wiring diagram
attached and in compliance with local and international regulations.
7.4.1 Recommended MGT switch to be inserted upstream of the line
DDS - DCS
Single-phase
Three-phase
Models
40
50
60
70
90
100
160
190
210
230
300
Without electric heating
element
C10
C10
C10
C10
C16
C16
C20
C20
C16
C16
C16
With electric heating element
C16
C16
C20
C20
C32
C32
C40
C40
C32
C32
C32
DVS
Single-phase
Three-phase
Models
70
90
100
160
190
210
230
Without electric heating
element
C10
C16
C16
C20
C20
C16
C16
With electric heating element
C20
C32
C32
C40
C40
C32
C32
DOS
Single-phase
Three-phase
Models
70
90
100
160
190
210
230
Without electric heating
element
C10
C16
C16
C20
C20
C16
C16
With electric heating element
C20
C32
C32
C40
C40
C32
C32
