Hikmicro GRYPHON Series User Manual

Thermal Monocular User Manual
16
4. Rotate the wheel to move the cursor until it reaches the defective pixel.
5. Press to set the axis as N, and rotate the wheel to select DPC.
6. Press to correct the defective pixel.
Note
● The selected defective pixel can be magnified and displayed at the bottom right of the
interface.
Figure 3-3 Correct Defective Pixel
● If the screen OSD blocks the dead pixel, the device performs mirror display automatically.
Figure 3-4 Mirror Effect
3.10 Flat Field Correction
This function can correct non-uniformity of display.
Steps
1. Hold to go to the menu.

Hikmicro GRYPHON Series Specifications

General

Detector Pitch	12 μm
Frame Rate	50 Hz
Video Recording	Yes
Photo Capture	Yes
Ingress Protection	IP67
Thermal Resolution	384 × 288 or 640 × 512
Detection Range	Up to 1800 m
Display	1024x768
Lens Options	35mm
Battery Type	Rechargeable Li-ion
Wi-Fi	Yes
Objective Lens Diameter	35mm
Operating Temperature	-20 °C
Digital Zoom	1 ×, 2 ×, 4 ×, 8 ×
