Hikmicro GRYPHON Series User Manual

Thermal Monocular User Manual
24
Chapter 6 System Settings
6.1 Synchronize Time
Steps
1. Hold to show the menu.
2. Rotate the wheel to select , and press to enter the time setting interface.
3. Press to switch the time system, and rotate the wheel to select the time and date to be
synchronized.
4. Press and rotate the wheel to set the time and date, and press again to finish the
setting.
5. Hold to save settings and exit.
6.2 Language Settings
You can select the device language in this function.
Steps
1. Hold to show the menu.
2. Rotate the wheel to select , and press to enter the language configuration interface.
3. Rotate the wheel to select the language as required, and press to confirm.
6.3 Unit Settings
You can switch the unit for fusion level and laser ranging functions.
Steps
1. Hold to show the menu.
2. Rotate the wheel to select , and press to switch the unit. Yard and m (meter) are
selectable.
3. Hold to save settings and exit.
6.4 CVBS Output
The CVBS output is used to debug the device. You can also view the device image on the display

Hikmicro GRYPHON Series Specifications

General

Detector Pitch	12 μm
Frame Rate	50 Hz
Video Recording	Yes
Photo Capture	Yes
Ingress Protection	IP67
Thermal Resolution	384 × 288 or 640 × 512
Detection Range	Up to 1800 m
Display	1024x768
Lens Options	35mm
Battery Type	Rechargeable Li-ion
Wi-Fi	Yes
Objective Lens Diameter	35mm
Operating Temperature	-20 °C
Digital Zoom	1 ×, 2 ×, 4 ×, 8 ×
