Hikmicro GRYPHON Series User Manual

Thermal Monocular User Manual
12
– refers to jungle mode and is recommended in hunting environment.
3. Hold to save settings and exit.
3.5 Set Palettes
You can select different palettes to display the same scene in different effects.
Steps
1. Hold to go to the menu.
2. Rotate the wheel to select .
3. Press to go to the palettes interface.
4. Rotate the wheel to select the palettes required, and press to enable it/them.
Note
● At least one palette should be enabled.
● The default palettes are White Hot, Optical, and Fusion.
5. Hold to save the settings and exit.
6. Press in live view interface to switch the selected palettes.
Optical
The image of optical channel is displayed in this mode.
White Hot
The hot part is light-colored in view. The higher the temperature is, the lighter the color is.

Hikmicro GRYPHON Series Specifications

General

Detector Pitch	12 μm
Frame Rate	50 Hz
Video Recording	Yes
Photo Capture	Yes
Ingress Protection	IP67
Thermal Resolution	384 × 288 or 640 × 512
Detection Range	Up to 1800 m
Display	1024x768
Lens Options	35mm
Battery Type	Rechargeable Li-ion
Wi-Fi	Yes
Objective Lens Diameter	35mm
Operating Temperature	-20 °C
Digital Zoom	1 ×, 2 ×, 4 ×, 8 ×
