Thermal Image Scope User Manual
16
3.9 Correct Defective Pixel
The device can correct the defective pixels on the screen which are not performed as expected.
Steps
1. In main menu mode, select Function Settings, and press the wheel to enter the sub-
menu.
2. Rotate the wheel to select , and press the wheel to enter the DPC setting interface.
3. Rotate the wheel to select or axis and press the wheel to confirm. If you select X-
axis, the cursor moves left and right; if you select Y-axis, the cursor moves up and down.
4. Rotate the wheel to move the cursor until it reaches the defective pixel.
5. Select , and press the wheel to correct the dead pixel.
Note
● The selected defective pixel can be magnified and displayed on the right of the interface.
● If the screen OSD blocks the defective pixel, move the cursor to reach the defective pixel, then
the device performs mirror display automatically as shown in the figures below.
