Thermal Image Scope User Manual
19
Chapter 4 Zeroing
4.1 Select Zeroing Profile
If different users use the same device, the users can configure and save the zeroing settings in
their respective zeroing profile.
Steps
1. In the main menu, rotate the wheel to select .
2. Press and rotate the wheel to switch the zeroing profile.
3. Hold the wheel to save and exit.
Result
The right top of the image displays the reticle information. For example, A1-100 m means you are
using the No. 1 reticle in zeroing profile A, and the set range is 100 m.
Figure 4-1 Using a Zeroing Profile
Note
There are 5 zeroing profiles in total, and you can configure 5 reticles in each zeroing profile.
4.2 Correct Reticle
Correcting the reticle can help you aim at the target with high accuracy by marking the offset
between the big reticle and small reticle. Functions such as Freeze and Zoom help to adjust the
reticle more accurately.
