Hikmicro Pocket Series User Manual

Pocket Series User Manual
3
Figure 1-1 Appearance
Table 1-1 Button and Interface Description
No.
Description
Function
1
Home Key
Tap to return to the live view interface.
2
File Key
Tap to enter albums.
3
Settings Key
Tap to enter settings interface.
4
Flash Light
Fill light on objects and output flashing
alarm.
5
Thermal Lens
View the thermal image.
6
Optical Lens
View the optical image.
7
Power Key
Hold to power on/off the device.
8
Capture Key
 Press in live view mode: capture
snapshots/stop recording
 Press in menu mode: return to the live
view interface
 Hold: start recording

Hikmicro Pocket Series Specifications

General

Wi-Fi	Yes
Laser Pointer	Yes
Accuracy	±2°C or ±2%
Image Modes	Thermal, PIP
Battery Type	Li-ion Battery
Sensor Type	Uncooled VOx microbolometer
Spectral Range	8 to 14 μm
Resolution	384 × 288 (Pocket2)
