User Manual of 9600/8600/7700/7600 Series NVR
139
address ranging from 239.252.0.0 to 239.255.255.255.
Steps:
1. Enter the Network Settings interface.
Menu >Configuration> Network
2. Select the More Settings tab to enter the More Settings interface, as shown in Figure 9. 15.
3. Set Multicast IP, as shown in Figure 9. 17. When adding a device to the Network Video Surveillance
Software, the multicast address must be the same as the NVR‟s multicast IP.
Figure 9. 17 Configure Multicast
4. Click to save and exit the interface.
Note: The multicast function should be supported by the network switch to which the NVR is connected.
9.2.7 Configuring RTSP
Purpose:
The RTSP (Real Time Streaming Protocol) is a network control protocol designed for use in communication
systems to control streaming media servers.
Steps:
1. Enter the Network Settings menu
Menu >Configuration> Network
2. Select the More Settings tab to enter the More Settings menu, as shown in Figure 9. 15.
Figure 9. 18 RTSP Settings Interface
3. Enter the RTSP port in the text field of RTSP Service Port. The default RTSP port is 554, and you can
change it according to different requirements.
4. Click to save and exit the menu.
9.2.8 Configuring Server and HTTP Ports
Purpose:
You can change the server and HTTP ports in the Network Settings menu. The default server port is 8000 and the
default HTTP port is 80.
Steps:
1. Enter the Network Settings interface.
Menu >Configuration> Network
2. Select the More Settings tab to enter the More Settings interface, as shown in Figure 9. 15.
3. Enter new Server Port and HTTP Port.
