User Manual of 9600/8600/7700/7600 Series NVR
177
11.5 Configuring Quota Mode
Purpose:
Each camera can be configured with allocated quota for the storage of recorded files or captured pictures.
Steps:
1. Enter the Storage Mode interface.
Menu > HDD > Advanced
2. Set the Mode to Quota, as shown in Figure 11. 18.
Note: The NVR must be rebooted to enable the changes to take effect.
Figure 11. 18 Storage Mode Settings Interface
3. Select a camera for which you want to configure quota.
4. Enter the storage capacity in the text fields of Max. Record Capacity (GB) and Max. Picture Capacity
(GB), as shown in Figure 11. 19.
Figure 11. 19 Configure Record/Picture Quota
5. You can copy the quota settings of the current camera to other cameras if required. Click the Copy button to
enter the Copy Camera menu, as shown in Figure 11. 20.
