AX PRO User Manual
50
2. Slide the slider to enable ISUP protocol.
3. Select the Address Type as IP or Domain Name.
4. Enter IP address or domain name according to the address type.
5. Enter the port number for the protocol.
Note
By default, the port number for ISUP is 7660.
6. Set an account, including the Device ID and ISUP Login Password.
7. Select Communication Mode.
Auto
The system will select the communication mode automatically according to the sequence of,
wired network, Wi-Fi network, and cellular data network. Only when the current network is
disconnected, will the device connect to other network.
Wired Network & Wi-Fi Priority
The connection priority order from high to low is: wired network, Wi-Fi, cellular data
network.
Wired &Wi-Fi
The system will select wired network first. If no wired network detected, it will select Wi-Fi
network.
Cellular Data Network
The system will select cellular data network only.
8. Click Save.
